The power of two, FABJET-DUO is an Indian-made direct to textile printing machine in bangladesh, designed after recognizing the need in the market for a printer that can work simultaneously with different inks and fabrics. This revolutionary printer is an avant-garde 3.2 meters wide format fabric printer offering the 'Power of Two' in one machine for printing home textiles. As the name suggests, this printer has a dual ink supply system which gives one the freedom to choose between any two of the three inks; Reactive, Disperse, and Pigment and thus by just a flick of a switch, the printer becomes a reactive or pigment or disperse printing machine. This Indian made direct to textile printing machine achieves speedy and brilliant results at minimized costs.
The advantages of the Fabjet Duo include:
FABJET-DUO - Wide Format disperse fabric printer in bangladesh comes with a unique feature of choosing any two inks at the same time, out of the three inks- Disperse, Reactive, and Pigment. This makes it first-ever Indian textile printing machine that runs with dual inks. The brilliance of FABJET-DUO, our wide format fabric printer can be measured through its ability to double your profit and ROI. This is a transforming machine that meets designer home textile needs with ease. This versatile Indian made direct to textile printing machine gives you the freedom to choose between a variety of fabrics and inks, thus opening endless avenues for your business. This brilliant wide format fabric printer gives high-quality prints at a super speed in just a one-step process. With FABJET-DUO, produce vivid and sharp images at low running costs with reduced consumption of ink. Smooth gradations and no limitations on colors make this machine a perfect solution for numerous applications.
Fabjet Duo | |||||
---|---|---|---|---|---|
CONFIGURATION
|
N4412
|
N4424
|
|||
Printing Technology |
Industrial Grade Jetting Assemblies
|
||||
No. of Print Heads |
8
|
8
|
|||
Print Heads | Type |
Industrial Grade Jetting Assemblies
|
|||
Resolution |
Upto 1400 DPI
|
||||
Height Adjustment |
upto 30mm
|
||||
Cleaning Method |
Pressure Purge and Wiping
|
||||
Wetting Control |
Piezoelectric Actuations
|
||||
Inks | Types |
Reactive / Disperse / Pigment / Acid
|
|||
No of colors |
4
|
4
|
|||
Supply |
2.5 Ltr, Bulk ink Supply System with inline degassing
|
||||
Fabric | Types |
Cotton,Viscose,Polyester,Polyamide,Silk,Wool
|
|||
Max.Thickness |
Upto 5mm
|
||||
Max.Width |
3200mm
|
||||
Roll Width |
400mm
|
||||
Fabric Drying System |
Infrared Heaters
|
||||
Operating Interface |
Touch screen
|
||||
Printing Interface |
High Speed USB
|
||||
RIP Software Supported |
ErgoSoft (Colorjet Editions)
|
||||
File Format |
JPEG, TIFF, BMP/PDF (RGB, CMYK)
|
||||
Power Supply |
220 V, 32 A Single/Three phase load distribution, 50Hz,
|
||||
Operating Conditions |
Temperature 18 to 28 C, Humidity: 35-80% RH ( Non-Condensing)
|
||||
Outer Dimension/Weight |
5300 mm x 1440 mm x 1650 mm (LxWxH) 1800 Kg Approx.
|
||||
Speed (In Sq. Meter/Hrs) |
Print DPI
|
Passes
|
N4412
|
N4424
|
|
Mode 1 |
|
3
|
NA
|
62
|
|
Mode 2 |
|
4
|
NA
|
46
|
|
Mode 3 |
720 x 720
|
4
|
41
|
49
|
|
Mode 4 |
720 x 540
|
6
|
22
|
26
|
|
Mode 5 |
720 x 720
|
8
|
20
|
24
|
